Technical Specs

Parts breakdown set up manuel

TM Dirt Bikes 31-33-36-38

Parts

SPECIFICATONS
POWER SYSTEM
Engine Type	CBS300, Single Cylinder, 4-Stroke,4-Valve, Liquid Cooling, SOHC
Displacement	279 ml
Max Power	20kw / 8500rpm - 27 Hp
Max Torque	23/7000 N.m/r/min
Compression Ratio	11.1:1
Shift Type	Manual Wet Multi-Plate, Constant mesh, two stage transmission, 5-Gears
Start Type	Electric & Kick Start
Carburetor	PWK34
Ignition	Digital CDI
Drive Train	#520 Chain, FT: 13T/RR: 49T Sprocket
PERFORMANCE
Front Fork	Φ53*Φ58.5-910mm Inverted Hydraulic Dual Adjustable Forks, 245mm Travel
Rear Shock	460mm Dual Adjustable Shock with Ballonet, 120mm Travel
Front Wheel	7116 Aluminum Rim, Gravity Cast Hub, FT: 1.6 x 21
Rear Wheel	7116 Aluminum Rim, Gravity Cast Hub, RR: 2.15 x 18
Front Tires	80/100-21
Rear Tires	110/100-18
Front Brake	Dual Piston Caliper, 240mm Disc
Rear Brake	Single Piston Caliper, 240mm Disc
DETAILS
Frame	Central Tube High Strength Steel Frame
Swing-Arm	Steel Swingarm,L=590mm
Handle Bar	Tapered Aluminum #7075
Overall Size	86.6"X33.9"49.2"/2200x860x1250mm
Packing Size	67.5"X18"X34"/1715x450x860mm
Wheel Base	59"/1500 mm
Seat Height	37"/940 mm
Ground Clearance	11.8"/300 mm
Fuel Capacity	6.5 L / 1.72 Gal.
N.W	234lbs/117 KG
G.W	326lbs/148KG

Product Dimensions

• L x W x H: 6.5*18*34 mm
• Weight : 326

More Pictures
